Used BMW 1 Series wing mirror: which one fits your car


The right used BMW 1 Series wing mirror is the one that matches your generation and facelift, the correct side of the car, the wiring plug on your door loom and, ideally, your paint code. Get those four right and a used mirror powers, heats, folds and indicates like the original. A complete used mirror from a donor car costs far less than buying the glass, motor, cover and indicator separately as new parts, and it arrives already assembled and matched. The trap with this part is the cheap glass and cover listings, which only help if that is all you have broken.

Which generation of 1 Series do I have?

BMW changed the door mirror with each generation and at each facelift, and none of them swap. The first generation E87 five door ran from 2004 to 2011, joined by the E81 three door, the E82 Coupe and the E88 Convertible, and all four had an LCI facelift in 2007 that changed the mirror housing and moved the indicator into it. The second generation F20 five door and F21 three door ran from 2011 to 2019 with an LCI in 2015. The F40 arrived in 2019 and is a front wheel drive car with a different mirror again. Your registration confirms the generation and the build date, which matters most around the 2007 and 2015 facelifts.

Body Years Mirror notes
E87, E81 pre LCI 2004 to 2007 Indicator in the front wing, not in the mirror
E87, E81, E82, E88 LCI 2007 to 2013 Indicator in the mirror housing, power fold on some trims
F20, F21 pre LCI 2011 to 2015 LED indicator, power fold and auto dim optional
F20, F21 LCI 2015 to 2019 Revised housing, same options
F40 2019 on Different car and mirror

Should I buy the complete mirror or just the glass or cover?

It depends what broke. If only the glass has cracked, a replacement glass clips in and is cheap. If only the painted cap is scuffed, a cap in your colour is the answer, and we list those separately when we have them. If the housing took the hit, the motor has stopped adjusting, the fold no longer works or the indicator has failed, buy the complete used assembly. You get the motor, the heated glass, the indicator, the cover and the base together, already working as a unit, for less than the sum of the new parts. That is what a breaker supplies and it is why used wins on this job.

Which side do I need, nearside or offside?

Mirrors are handed and the glass is curved differently on each side, so there is no universal unit. In the UK, nearside is the passenger side, the left of the car as you sit in the driver's seat. Offside is the driver's side, the right. Our listings say LH passenger or RH driver, which mean the same thing on a right hand drive car. Avoid mirrors from left hand drive imports: the glass curvature is set for the other side of the road and the driver's side glass is often flat rather than convex. Our post on nearside or offside covers the terms in detail.

How do I match the wiring plug?

This is the check most buyers miss. The same 1 Series was built with mirrors that are heated and adjustable only, heated with power fold, heated with power fold and auto dimming, and with or without a puddle lamp. Each option adds pins to the connector, so count the pins on the plug inside your door and compare them with the listing photos. A mirror with more functions than your car has will fit physically but the extra features will not work, and one with fewer functions will leave you with a dead fold or indicator. The BMW part number on the back of the mirror base pins all of this down, so if you can read yours, send it to us with your registration.

Does the paint code matter?

The mirror cap is painted body colour on most 1 Series, so matching your paint code gives you a straight fit with no painting. The code is on the VIN plate under the bonnet or on the door shut sticker, and is a three character code such as 475 Black Sapphire, A22 Sparkling Graphite or 354 Titansilber, all of which appear in our recent 1 Series listings. If we have the right mirror in the wrong colour, the cap is a simple swap, and plenty of owners run gloss black caps regardless. A mirror in the right colour is worth waiting for if you want it invisible; a mirror in the wrong colour with a correct cap transferred across is the next best thing.

How do I fit a used 1 Series wing mirror?

Allow an hour with basic tools. The inner triangle trim pops off to reach the mirror bolts and the connector, and on some cars the top edge of the door card has to come away too. Disconnect the battery before unplugging the mirror if your car has auto dimming, so you do not log a fault. Fit the new mirror, plug in, reconnect and test adjustment, heating, fold and the indicator before you put the trim back. On cars with memory seats the mirror may need a short drive or a diagnostic reset to recalibrate its fold position. Our 3 Series door guide covers the related job of replacing the whole door.

What we usually have in stock for the BMW 1 Series

Stock changes daily as cars arrive and parts sell, so the used BMW 1 Series parts collection shows what is live now, with other makes in glass, mirrors and wipers. Recent 1 Series mirror and related items include:

  • E87 120d door mirror, passenger side, Sparkling Graphite A22
  • E87 120d door mirror, driver side, Sparkling Graphite A22
  • E87 118d M Sport door mirror, passenger side, Titansilber 354
  • E87 118d M Sport door mirror cover, driver side, Titansilber 354
  • E87 120d rear view mirror surround trim, 7069492
  • E87 120d rear lamp, driver side, 6224502
  • E87 120d rear lamp, passenger side, 6924501
  • E81 E87 118d alternator, 12317802261
  • F20 F21 headlight control switch, 9393949

If the mirror you need is not showing, send us your registration, the side and your paint code and we will tell you what is on the shelf or coming in.

Buy with confidence

Every part we sell comes off a known donor car at our Doncaster yard, is inspected before listing and is photographed so you see the actual item, not a stock image. Tracked UK delivery is included on every order and is free on most parts; panels, engines and gearboxes carry a charge shown on the product page. Order before 2pm on a working day for same day dispatch. If a part is not right, you have 30 day returns. Send us your registration and the part you need and we will confirm fitment before you buy. Parts worth your trust.

Written by Bogdan Dragos, founder of Partsworth, Doncaster. Part numbers and fitment details are checked against parts in our yard, and delivery and returns wording matches our live policies.

Frequently asked questions

Will a wing mirror from a different 1 Series fit?

Not across generations or facelifts. The E87 family (2004 to 2013) changed its mirror at the 2007 LCI, the F20 and F21 (2011 to 2019) changed again at the 2015 LCI, and the F40 (2019 on) is different again. Match your generation and build date, then the part number on the mirror base, confirmed by your registration.

Is it better to buy the whole mirror or just the glass?

Buy the glass if only the glass is broken and a cap if only the cap is scuffed. If the housing, motor, fold mechanism or indicator is damaged, a complete used assembly is better value because everything comes matched and working as one unit, for less than the new parts added together.

How do I make sure a used mirror works after fitting?

Count the pins on your old mirror's wiring plug and compare them with the listing photos, because heating, power fold, auto dim and puddle lamps each add pins. A mirror with a different pin count will fit physically but some functions will not work. Matching the BMW part number on the mirror base covers this.

Do the mirror caps need to match my colour?

Caps are painted body colour on most 1 Series, so matching your three character paint code from the VIN plate gives a straight fit. If the cap is the wrong colour it is a simple swap, and many owners fit gloss black caps regardless. Our listings state the colour code where it is known.

What if the mirror does not fit when it arrives?

You have 30 day returns on every part we sell. To avoid the hassle, send us your registration, the side and your paint code before ordering and we will confirm fitment against the BMW part number for your exact car.
